Category | Specification Parameters |
System driven | Bilateral AC Linear Motor |
Tray pitch | 600 / 750 / 800 / 1200mm (2 trays and 1 belt) |
Tray length | 700-1100/1400mm |
Width of tray belt | 420-620mm |
Running speed | 1.2 - 2.4m/s (optional) |
Sorting capacity (one-side) | More than 12,000 units per hour |
Ways to provide parcels | Automatic / Semi-Automatic / Manual Direct In-put (optional) |
System model | 2-N Logical Sorting System with 1 Ring Circle (Personalized Configuration) |
Automatic / Semi-automatic Loading of parcel machine | Loading capacity | 2500 - 3000 per hour |
Loading of parcel speed | 1 - 2.3 m/min | |
Power | Section 3 / 4 | |
Walking track | Straight track section length | 2800 / 3000mm |
Turning section central radius | 34400mm / 4586mm etc. | |
Track material | 3T cold plate | |
Surface treatment | Spraying | |
Sorting tray | Driving mode | 48V bidirectional DC roller |
Pitch distance | 600-1200mm | |
Pallet Length | 700-1100mm | |
Skin bandwidth | 450-620mm | |
Maximum load of single tray | 30kg | |
Maximum size of sorting goods | 1000L*500W*500H | |
Code Reader | Specifications | Selection by bar code |
Cooperative brand | Datalogic / Sick / Cognex / Victronic | |
Out-feed chute | Chute length | 2800mm / 3000 |
Inclination angle | 27° | |
Texture of material | 3T cold plate | |
Construction roller track | Roller pitch | 700mm/750mm |
Roller length | 1000mm | |
Bag holder | Bag support pitch | 700mm / 750mm |
Bag support ring | 500*500*Ø15mm |
Note: The above are the company's existing standard equipment parameters, supporting non-standard customization design.
